M2Y1G64CB88A9N / M2Y2G64CB8HA9N

1GB: 128M x 64 / 2GB: 256M x 64

Unbuffered DDR3 SDRAM DIMM

REV 1.0 12

11/2008

NANYA TECHNOLOGY CORP. reserves the right to change Products and Specifications without notice.

Operating, Standby, and Refresh Currents

CASE

= 0 °C ~ 85 °C; V

DDQ

= V

= 1.5V ± 0.075V (1GB, 1 Rank, base on 128Mx8 DDR3 SDRAMs)

Symbol

Parameter/Condition

DDR3-1066

DDR3-1333

DDR3-1600

Unit

I DD0

Operating Current: one bank activate/Precharge

968

1056

I DD1

Operating Current: one bank activate/Read/Precharge

1100

1188

1276

I DD2P(0)

Precharge Power-Down Current Fast Exit-MR0 bit A12=0

141

I DD2P(1)

Precharge Power Down Current Slow Exit-MR0 bit A12=1

264

I DD2N

Precharge Standby Current

572

616

660

I DD2Q

Precharge Quiet Standby current

484

528

572

I DD3P

Active Power-Down Current Always Fast Exit

352

396

440

I DD3N

Active Standby Current

572

616

660

I DD4W

Operating Current: Burst Write

1408

1760

2024

I DD4R

Operating Current: Burst Read

1408

1760

2200

I DD5B

Burst Refresh Current

2200

2376

2552

I DD6

Self-Refresh Current Normal Temperature Range (0-85C)

123

I DD7

All Bank Interleave Read Current

2640

3168

3432

Note: Module IDD was calculated from component IDD. It may differ from the actual measurement.

Operating, Standby, and Refresh Currents

CASE

= 0 °C ~ 85 °C; V

DDQ

= V

= 1.5V ± 0.075V (2GB, 2 Ranks, base on 128Mx8 DDR3 SDRAMs)

Symbol

Parameter/Condition

DDR3-1066

DDR3-1333

DDR3-1600

Unit

I DD0

Operating Current: one bank activate/Precharge

1540

1672

1716

I DD1

Operating Current: one bank activate/Read/Precharge

1672

1804

1936

I DD2P(0)

Precharge Power-Down Current Fast Exit-MR0 bit A12=0

282

I DD2P(1)

Precharge Power Down Current Slow Exit-MR0 bit A12=1

528

I DD2N

Precharge Standby Current

1144

1232

1320

I DD2Q

Precharge Quiet Standby current

968

1056

1144

I DD3P

Active Power-Down Current Always Fast Exit

704

792

880

I DD3N

Active Standby Current

1144

1232

1320

I DD4W

Operating Current: Burst Write

1980

2376

2684

I DD4R

Operating Current: Burst Read

1980

2376

2860

I DD5B

Burst Refresh Current

2772

2992

3212

I DD6

Self-Refresh Current Normal Temperature Range (0-85C)

246

I DD7

All Bank Interleave Read Current

3212

3784

4092

Note: Module IDD was calculated from component IDD. It may differ from the actual measurement.
