M2F1G64CB88A4N / M2F2G64CB8HA4N

1GB: 128M x 64 / 2GB: 256M x 64

Unbuffered DDR3 SDRAM DIMM Preliminary

REV 0.1 10

06/2008

NANYA TECHNOLOGY CORP. reserves the right to change Products and Specifications without notice.

Serial Presence Detect -- Part 2 of 2 (2GB)

256Mx64 2 Ranks UNBUFFERED DDR3 SDRAM DIMM based on 128Mx8, 8Banks, 8K Refresh, 1.5V DDR3 SDRAMs with SPD

Byte

Description

SPD Entry Value

Serial PD Data Entry

(Hexadecimal)

Note

-BE

-CG

-DG

-BE

-CG

-DG

Module thickness (Max)

Standard

Raw Card ID reference

Undefined

DRAM address mapping edge connector

Nanya Technology

830B

64-116

Reserved

Undefined

117-118

Module manufacture ID

Undefined

119-125

Module information

Undefined

126-127

CRC

Undefined

00000000

128-145

Module part number

Calculated Value

ABEF

79C9

6B97

146

Module die revision

ASCII values

147

Module PCB revision

Undefined

148-149

DRAM device manufacturer ID

Undefined

150-175

Manufacturer reserved

Nanya Technology

830B

176-255

Customer reserved

Undefined

SPD Note

SPD Entry Value

Serial PD Data Entry (Hexadecimal)

M2F1G64CB88A4N-BE

4D3246324736344342384841344E2D424520

M2F1G64CB88A4N-CG

4D3246324736344342384841344E2D434720

M2F1G64CB88A4N-DG

4D3246324736344342384841344E2D444720
